DZL Series Small Four-Wheel Guardrail Pile Driver
Цена: по запросу
Минимальный заказ: 1 шт.
- Introduction to DZL Series Small Four-Wheel Guardrail Pile Driver
The DZL series small four-wheel guardrail pile driver is a multi-functional engineering machinery specially designed for highway guardrail construction. Powered by a diesel engine and adopting a full hydraulic transmission system, it features self-propelled capability without the need for external traction. Its core functions include steel pipe pile driving, extraction, and drilling, enabling it to complete guardrail installation and emergency repair operations in various complex stratum conditions. It fully embodies advantages such as convenient mobility and diversified functions, and is widely used in expressways, municipal engineering, and field construction sites.
2.Features of DZL Series Small Four-Wheel Guardrail Pile Driver
2.1 Power configuration: Equipped with a high-performance diesel engine, it provides a strong power source for construction operations, with significantly improved power reliability and fuel economy.
2.2 Hydraulic system: Advanced hydraulic system with high-quality hydraulic components and strict assembly processes ensures high efficiency and durability of the hydraulic system.
2.3 Design: The overall frame structure is sophisticated with qualified materials, featuring high strength and good stability. The design conforms to industrial aesthetics, and the operator’s working space is more spacious.
2.4 Production process: The production process is more reasonable. Wear-resistant components are all treated with heat treatment. The welding process is rigorous, and after stress relief treatment, it is not easy to deform. - Parameters of DZL Series Small Four-Wheel Guardrail Pile Driver
Pile driver model DZL-Ⅰ DZL-Ⅱ
Function Piling, pile extraction Piling, pile extraction, drilling
Applicable pipe piles 110⁄140 round piles, 130 square piles 110⁄140 round piles, 130 square piles
Hydraulic hammer 260 260
Drilling rig power head / Hydraulic-pneumatic type
Drilling diameter / 120-250mm
Engine 490 490
Rated power 40kW 40kW
Brake system Air brake Air brake
Total machine weight 2300kg 2330kg
Transportation size L3200*W2100*H2700mm L3200*W2100*H2700mm
Note: The product is continuously improved. Changes may be made without prior notice. Please refer to the actual product.
Бренд: HUAXIAMASTER
Модель: DZL-Ⅰ DZL-Ⅱ
Страна: 中国
Вес: 6200 кг
Размеры: 450/210/250
Чтобы купить DZL Series Small Four-Wheel Guardrail Pile Driver оптом по цене по запросу, свяжитесь с поставщиком. Компания поставщик — Master (Jining) Heavy Industry Machinery Co Ltd из города Гонконг (Central and Western). Минимальная сумма оптового заказа: 1000000 руб. Минимальная партия 1 шт. Способы оплаты: наличными, безналичная оплата, кредитные карты, электронные деньги.
Дата обновления: 12.07.2025
